Main Specifications
Product Description D-Link DGS 108 - switch - 8 ports - desktop
Device Type Switch - 8 ports
Enclosure Type Desktop
Ports 8 x 10/100/1000
MAC Address Table Size 8K entries
Features Flow control, auto-sensing per device, auto-negotiation, packet filtering, store and forward
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x
Dimensions (WxDxH) 7.8 in x 4.5 in x 1.2 in
Weight 1.1 lbs
Manufacturer Warranty 5 years warranty
General
Device Type Switch - 8 ports
Enclosure Type Desktop
Ports 8 x 10/100/1000
MAC Address Table Size 8K entries
Features Flow control, auto-sensing per device, auto-negotiation, packet filtering, store and forward
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x
Status Indicators Link activity, power
Expansion / Connectivity
Interfaces 8 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Power
Power Device Power adapter - external
Power Consumption Operational 6.7 Watt
Miscellaneous
Width 7.8 in
Depth 4.5 in
Height 1.2 in
Weight 1.1 lbs
Compliant Standards Plug and Play, FCC Class B certified, CE, CSA
Manufacturer Warranty
Service & Support 5 years warranty
Service & Support Details Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 104 °F
Humidity Range Operating 10 - 95%
