Description:Main Specifications
Product Description HP EliteOne 840 G9 - Wolf Pro Security - all-in-one - Core i5 13500 2.5 GHz - vPro - 8 GB - SSD 256 GB - LED 23.8" - US - with HP Wolf Pro Security Edition (1 year)
Type Personal computer - all-in-one
Platform Technology Intel vPro Platform
Localization Language: English / region: United States
Processor Intel Core i5 (13th Gen) 13500 / 2.5 GHz (, up to 4.8 GHz, (14-core)
Processor Main Features Intel Turbo Boost Technology, Intel Smart Cache
Cache Memory 24 MB L3 cache
Cache Per Processor 24 MB
RAM 8 GB (installed) / 64 GB (max) - DDR5 SDRAM
Hard Drive SSD 256 GB - PCI Express 4.0 x4 - M.2 2280 - NVM Express (NVMe), triple-level cell (TLC)
Optical Storage No optical drive
Monitor 23.8" - LED - 1920 x 1080 (Full HD) @ 60 Hz - 16:9
Graphics Controller Intel UHD Graphics 770 Dynamic Video Memory Technology
Camera Yes
Audio Output Stereo
Networking GigE, 802.11a, 802.11b/g/n, Wi-Fi 5, 802.11ax (Wi-Fi 6E), Bluetooth Dual-Mode
Keyboard US
Power (50/60 Hz)
OS Provided Windows 11 Pro
Software Included HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP Client Catalog (free download), HP Driver Packs, HP Image Assistant (free download), HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Sure Sense, HP SureStart, HP Sure Admin, HP QuickDrop, HP Client Management Script Library (free download), HP BIOSphere Gen6, myHP, Touchpoint Customizer for Commercial, HSA Fusion for Commercial, HSA Telemetry for Commercial, HP Desktop Support Utilities, HP Client Security Manager Gen7, HP Easy Clean, Absolute Persistence Module, HP Smart Support, HP Manageability Integration Kit (free download), HP Connect for Microsoft Endpoint Manager, HP Patch Assistant (free download), HP PC Hardware Diagnostics Windows, HP Sure Run Gen6, HP Sure Recover Gen6, HP Easy Clean Keyboard Driver
Dimensions (WxDxH) 21.2 in x 9.4 in x 22 in
Weight 20.41 lbs
Manufacturer Selling Program HP Smart Buy
Environmental Standards ENERGY STAR Qualified EPEAT Gold
Bundled with HP Wolf Pro Security Edition (1 year)
General
Platform Technology Intel vPro Platform
Type Personal computer
Product Form Factor All-in-one - with height-adjustable stand
Built-in Devices 5W stereo speakers
Sensors HP Tamper Lock
Embedded Security Trusted Platform Module (TPM 2.0) Security Chip
Localization Language: English / region: United States
Bundled with HP Wolf Pro Security Edition (1 year)
Expansion / Connectivity
Slots 1 (total) / 0 (free) x M.2 Card - 2230 (for WLAN) ¦ 3 (total) / 2 (free) x M.2 Card - 2280 (for SSD)
Interfaces 2 x USB 3.2 Gen 1 ¦ 3 x USB 3.2 Gen 2 (one of them is charging) ¦ 1 x USB-C 3.2 Gen 2 ¦ 1 x DisplayPort 1.4 ¦ 1 x HDMI ¦ 1 x USB-C 3.2 Gen 2x2 (charging) ¦ 1 x headphones/microphone (CTIA and OMTP headset support) ¦ 1 x LAN (Gigabit Ethernet)
Miscellaneous
Theft/Intrusion Protection Security lock slot (cable lock sold separately), chassis intrusion sensor
Security Slot Type Kensington security slot
VESA Mounting Interface 100 x 100 mm
Compliant Standards ICES-003, CCC, UL 60950-1, CSA C22.2 No. 60950-1-07, KCC Class B, CECP, VCCI Class B, SEPA, low halogen, UL 62368-1, FCC-15 (Class B), Japan PC Green Label, TUV Ultra Low Noise Certification, Taiwan Green Mark, Korea Eco-Label, TUV low blue light, CSA C22.2 No. 62368-1-14, TCO Certified 8.0, IT ECO Declaration
Manufacturer Selling Program HP Smart Buy
RAM
Installed Size 8 GB / 64 GB (max)
Technology DDR5 SDRAM
Effective Memory Speed 4800 MHz
Rated Memory Speed 4800 MHz
Form Factor SO-DIMM 262-pin
Slots 2 (total) / 1 (empty)
Configuration Features 1 x 8 GB
Networking
Interface (Bus) Type PCI Express Mini Card (M.2)
Ethernet Controller Intel I219-LM
Wireless LAN Supported Yes
Wireless NIC Intel Wi-Fi 6E AX 211
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth Dual-Mode
Features Dual stream (2x2)
Compliant Standards IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.11d, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11k, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v, Wi-Fi CERTIFIED 6
Power
Device Type Power supply
Voltage Required AC 100-240 V (50/60 Hz)
80 PLUS Certification 80 PLUS Platinum
Power Factor Correction Yes (active)
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 10 - 90% RH (non-condensing)
Cache Memory
Installed Size L3 cache - 24 MB
Cache Per Processor 24 MB
Optical Storage
Type No optical drive
Monitor
Monitor Type LED - IPS
Diagonal Size 23.8"
Native Resolution 1920 x 1080 (Full HD)
V-Sync Rate at Max Res. 60 Hz
Widescreen Display Yes
Image Aspect Ratio 16:9
Horizontal Viewing Angle 178
Vertical Viewing Angle 178
Color Gamut 72% NTSC
Pixel Pitch 0.2745 mm
Response Time 14 ms
Image Brightness 250 cd/m²
Image Contrast Ratio 1000:1
Monitor Features Anti-glare, Frame Rate Control (FRC), Low Blue Light technology, 8-bit(6-bit + FRC) Color Depth, tilt stand (-5°- 18°), 90° screen rotation, adjustable height (130 mm)
Graphics Controller
Graphics Processor Intel UHD Graphics 770 Dynamic Video Memory Technology
Video Interfaces HDMI, DisplayPort, USB-C
Audio Output
Sound Output Mode Stereo
Max Sampling Rate 192 kHz
Speakers Bang & Olufsen sound bar
Speakers Included 2 x right / left channel
Operating System / Software
OS Provided Windows 11 Pro English
Software HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP Client Catalog (free download), HP Driver Packs, HP Image Assistant (free download), HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Sure Sense, HP SureStart, HP Sure Admin, HP QuickDrop, HP Client Management Script Library (free download), HP BIOSphere Gen6, myHP, Touchpoint Customizer for Commercial, HSA Fusion for Commercial, HSA Telemetry for Commercial, HP Desktop Support Utilities, HP Client Security Manager Gen7, HP Easy Clean, Absolute Persistence Module, HP Smart Support, HP Manageability Integration Kit (free download), HP Connect for Microsoft Endpoint Manager, HP Patch Assistant (free download), HP PC Hardware Diagnostics Windows, HP Sure Run Gen6, HP Sure Recover Gen6, HP Easy Clean Keyboard Driver
Hard Drive
Type SSD - M.2 2280
Capacity 1 x 256 GB
Interface Type PCI Express 4.0 x4
Features NVM Express (NVMe), triple-level cell (TLC)
Camera
Camera Yes
Resolution (MP) 5 Megapixel
Features Swivel, 88° view
Audio Input
Type Dual array microphone
Input Device
Type Mouse, keyboard
Dimensions & Weight
Dimensions & Weight Details 21.2 in - 9.4 in - 22 in - 20.4 lbs - with stand ¦ 21.2 in - 2.1 in - 15.2 in - 15.4 lbs - without stand
Width 21.2 in
Depth 9.4 in
Height 22 in
Weight 20.41 lbs
Dimensions & Weight (Shipping)
Shipping Width 24.7 in
Shipping Depth 7.3 in
Shipping Height 26.6 in
Shipping Weight 27.56 lbs
Keyboard
Keyboard Name HP 320K
Interface USB
Localization & Layout US
Mouse
Mouse Name HP 125
Processor / Chipset
CPU Intel Core i5 (13th Gen) 13500
Clock Speed 2.5 GHz (P-core) / 1.8 GHz (E-core)
Max Turbo Speed 4.8 GHz (P-core) / 3.5 GHz (E-core)
Number of Cores 14-core
CPU Qty 1
Max CPU Qty 1
L2 cache 11.5 MB
Processor Main Features Intel Turbo Boost Technology, Intel Smart Cache
Chipset Type Intel Q670
Sustainability Information
EPEAT Compliant EPEAT Gold
ENERGY STAR Certified Yes
