Description:Main Specifications
Product Description HP Workstation Z2 G9 - Wolf Pro Security - SFF - Core i7 i7-14700 2.1 GHz - 16 GB - SSD 512 GB - US - with HP Wolf Pro Security Edition (1 year)
Type Workstation - small form factor
Bundled Services HP 1 year Wolf Pro Security Edition Service
Localization Language: English / region: United States
Processor 1 x Intel Core i7 (14th Gen) i7-14700 / 2.1 GHz (, up to 5.4 GHz, (20-core)
Processor Socket LGA1700 Socket
Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0
Cache Memory 33 MB L3 cache
Cache Per Processor 33 MB
RAM 16 GB (installed) / 128 GB (max) - DDR5 SDRAM - non-ECC
Storage Controller SATA/NVMe (SATA 6Gb/s / PCIe 4.0 x4 (NVMe))
Hard Drive SSD 512 GB - PCI Express - M.2 2280 - HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC)
Optical Storage No optical drive
Graphics Controller Intel UHD Graphics 770 Unified Memory Architecture (UMA)
Networking 1GbE
Keyboard US
OS Provided Windows 11 Pro
Software Included HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP ZCentral Remote Boost, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0
Color Black
Dimensions (WxDxH) 15.1 in x 12.1 in x 3.9 in
Weight 11.02 lbs
Manufacturer Selling Program HP Smart Buy
Environmental Standards ENERGY STAR Qualified
Manufacturer Warranty Limited warranty - parts and labor - 3 years - on-site
Bundled with HP Wolf Pro Security Edition (1 year)
General
Type Workstation
Bundled Services HP 1 year Wolf Pro Security Edition Service
Product Form Factor Small form factor
Built-in Devices Speaker
Embedded Security Trusted Platform Module (TPM 2.0) Security Chip
Color Black
Localization Language: English / region: United States
Bundled with HP Wolf Pro Security Edition (1 year)
Expansion / Connectivity
Bays 1 (total) / 1 (free) x external 3.5" ¦ 1 (total) / 1 (free) x external 5.25" Slim Line ¦ 1 (total) / 1 (free) x internal 3.5"
Slots 1 (total) / 1 (free) x PCIe 4.0 x16 ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 (PCIe 3.0 x4 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x1 ¦ 3 (total) / 2 (free) x M.2 Card - 2280 (for SSD) ¦ 1 (total) / 1 (free) x M.2 Card - 2230 (for WLAN)
Interfaces 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 4 x USB 3.2 Gen 2 (4 in front) (one of them is charging) ¦ 1 x USB-C 3.2 Gen 2x2 (1 in front) (charging) ¦ 1 x audio line-out ¦ 2 x DisplayPort 1.4 ¦ 3 x USB 2.0 ¦ 3 x USB 3.2 Gen 1 ¦ 1 x LAN (Gigabit Ethernet)
Manufacturer Warranty
Service & Support Limited warranty - parts and labor - 3 years - on-site
Miscellaneous
Theft/Intrusion Protection Security lock slot (cable lock sold separately)
Security Slot Type Kensington security slot
Compliant Standards RoHS, FIPS 140-2, WEEE, CECP, low halogen, ISV Certified
Manufacturer Selling Program HP Smart Buy
RAM
Installed Size 16 GB / 128 GB (max)
Technology DDR5 SDRAM - non-ECC
Effective Memory Speed 4800 MHz
Rated Memory Speed 4800 MHz
Form Factor DIMM 288-pin
Slots 4 (total) / 3 (empty)
Features Unbuffered
Configuration Features 1 x 16 GB
Networking
Ethernet Controller Intel I219-LM
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Features Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az
Power
Device Type Power supply
Power Provided 450 Watt
Efficiency 90%
Power Factor Correction Yes (active)
Environmental Parameters
Min Operating Temperature 41 °F
Max Operating Temperature 95 °F
Humidity Range Operating 10 - 85% RH (non-condensing)
Storage Controller
Type 1 x SATA/NVMe
Controller Interface Type SATA 6Gb/s / PCIe 4.0 x4 (NVMe)
Channel Qty 4
RAID Level RAID 0, RAID 1
Cache Memory
Installed Size L3 cache - 33 MB
Cache Per Processor 33 MB
Optical Storage
Type No optical drive
Monitor
Monitor Type None.
Graphics Controller
Graphics Processor Intel UHD Graphics 770 Unified Memory Architecture (UMA)
Video Interfaces DisplayPort
Audio Output
Compliant Standards High Definition Audio
Operating System / Software
OS Provided Windows 11 Pro English
Software HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP ZCentral Remote Boost, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0
Hard Drive
Type SSD - M.2 2280
Capacity 1 x 512 GB
Interface Type PCI Express
Features HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC)
Input Device
Type Mouse, keyboard
Dimensions & Weight
Width 15.1 in
Depth 12.1 in
Height 3.9 in
Weight 11.02 lbs
Dimensions & Weight (Shipping)
Shipping Width 7.8 in
Shipping Depth 19.3 in
Shipping Height 20.2 in
Shipping Weight 13.01 lbs
Keyboard
Keyboard Name HP 320K
Interface USB
Localization & Layout US
Mouse
Mouse Name HP 320M
Processor / Chipset
CPU Intel Core i7 (14th Gen) i7-14700
Clock Speed 2.1 GHz (P-core) / 1.5 GHz (E-core)
Max Turbo Speed 5.4 GHz (P-core) / 4.2 GHz (E-core)
Number of Cores 20-core
CPU Qty 1
Max CPU Qty 1
L2 cache 28 MB
CPU Upgradability Upgradable
Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0
CPU Socket LGA1700 Socket
Chipset Type Intel W680
Sustainability Information
ENERGY STAR Certified Yes
